EnGenius EAP-3660 Long Range Wireless Access Point/Repeater 802.11b/g EXCELLENT

EAP3660 offers a "smoke detector" look, and is a high-powered wireless access point / universal repeater that operates seamlessly in the 2.4GHz frequency spectrum supporting 802.11b (2.4GHz, 11Mbps) standard and SuperG 108Mbps high speed feature. It is the best way to add long range wireless capability to your existing wired network or to add bandwidth to your wireless installation.

EAP3660 features high wireless output power and receive sensitivity along with antenna diversity. High output power and high sensitivity extend wireless coverage to reduce the roaming between access points and to provide a reliable wireless connection. It also reduces the total cost of ownership on hardware.

To protect your wireless connectivity, it can encrypt all wireless transmissions through 64/128bits WEP data encryption and also supports WPA/WPA2. The MAC address filtering lets you select exactly which stations should have access to your network. In addition, the user isolation function can protect the private network between client users. The attractive design, high performance and array of features make the EAP3660 a suitable wireless solution for your residence or office.

AESTHETIC "SMOKE DETECTOR" DESIGN

Designed to blendin to various business environments, EAP3660 features minimal footprint and no protruding antennas. The unobtrusive design prevents tampering to protect your investment.

HIGH 600MW WIRELESS POWER

High-powered 600mW wireless power ensures robust signal to overcome long distances, which also offers superior WiFi coverage over leading brands.

MULTIPLE WIRELESS NAMES

EAP3660 broadcasts multiple WiFi networks with one device, and permits different levels of network access (VLAN Tagging).

POWER-OVER-ETHERNET (802.3AF) COMPLIANT

EAP3660 supports Power-over-Ethernet (IEEE 802.3af), with power and data over one single cable to ease deployment.

UNIVERSAL REPEATER

Universal repeater extends WiFi coverage into dead spots, minimizing trenching and cabling cost.

EMBEDDED ANTENNA

Designed to be deployable out of the box, EAP3660 features embedded antenna that delivers powerful omni-directional coverage.

Brand: EnGenius

Model: EAP-3660

Standards: IEEE 802.11b/g

Wireless Data Rates: Up to 108Mbps

Security:

Frequency Band: 2.4 GHz - 2.484 GHz

Channels: 11 Channels

Transmitted Power: IEEE802.11g

26dBm@6~24 Mbps

25dBm@36 Mbps

23dBm@48 Mbps

22dBm@54Mbps

IEEE802.11b

27dBm@1 ~ 11Mbps

Receiver Sensitivity IEEE802.11g

6Mbps@ -92dBm

54Mbps@ -74dBm

IEEE802.11b

1Mbps@ -97dBm

11Mbps@ -89dBm

Modulation OFDM: BPSK, QPSK, 16-QAM, 64-QAM

DBPSK, DQPSK, CCK

Interface Ethernet Port

LEDs  Power/ Status

LAN (10/100Mbps)

WLAN (Wireless Connection)
