Samsung MZVL8256HFJD-00B07 PM9C1b 256 GB PCI M.2 Express Gen.4 x4 512 Bytes SSD

MPN: MZVL8256HFJD-00B07

Main Features

• PCIe Gen.4 16Gb/s Interface, up to 4 Lanes
• PCI Express Base Specification Rev. 4.0
• PCI Express M.2 Specification Rev. 4.0
• NVM Express specification Rev. 2.0 (Mandatory Only)
• Power Saving Modes:
• Supporting APST
• Supporting L1.2 Mode
• Support Admin & NVM Command Set
• RoHS / Halogen Free Compliant
• TCG OPAL (v2.01) Compliant for SED
• Drive Configuration
• Capacity: 256 GB
• From Factor: M.2
• Interface: PCI Express Gen.4 x4
• Bytes per Sector: 512 Bytes
• Performance Specifications
• Data Transfer Rate (128KB):
• Sequential Read: Up to 6,200 MB/s
• Sequential Write: Up to 3,800 MB/s
• Data I/O Speed (4KB):
• Random Read: Up to 500K IOPS
• Random Write: Up to 800K IOPS
• Reliability Specifications
• Uncorrectable Bit Error Rate: < 1 sector per 10^15 bits read
• MTBF: 1.5 Million Hours
• Environmental Specifications
• Temperature: Operating: 0°C to 70°C; Non-operating: 40°C to 85°C
• Humidity (non-condensing): Non-operating: 5 ~ 95%
• Linear Shock (0.5ms duration with 1/2 sine wave): Non-operating: 1,500 Gpeak
• Vibration (20Hz ~ 2,000Hz, Sinusoidal): Non-operating: 20 Gpeak
• Power Specification
• Supply Voltage / Tolerance: 3.3V +/- 5%
• Voltage Ripple/Noise (max.): 200mV p-p
• Active (Typ, RMS):
• Read (3.3V): 4.8 W
• Write (3.3V): 4.3 W
• Idle (Typ.): 50 mW
• Sleep (Typ): 5 mW
• Physical Dimension
• Width: 22.00 +/- 0.15 mm
• Length: 80.00 +/- 0.15 mm
• Height: Max. 2.38 mm
• Weight: Under 9.0g
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.
