Asrock B650M PRO RS WIFI AM5 4xDDR5 SATA RAID 2.5G-LAN VGA HDI- DP BT WF ATX MB

ASRock B650M Pro RS WiFi Gaming Desktop Motherboard - AMD B650 Chipset - Socket AM5 - Micro ATX
Ryzen 7, Ryzen 5 Processor Supported - 192 GB DDR5 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - Gigabit Ethernet - 2.5Gigabit Ethernet - IEEE 802.11 a/b/g/n/ac/ax - HDMI - DisplayPort

• Ryzen 7 processors supported for enhanced, dependable system performance with maximum usability
• DDR5 SDRAM slot for convenient installation of memory
• Supported 0 RAID levels provide data reliability and fault tolerance
• Wireless support reduces the number of cables required to connect peripherals
• HDMI interface connects variety of HD devices including Gaming Controllers, Blu-ray players, laptops, PCs, digital cameras and many others for you to experience the ultimate HD display
• DisplayPort transmits both audio and video signals through a common channel to deliver versatile performance
• Thunderbolt host interface lets you move data between your devices and your computer with unprecedented speed
• Micro ATX form factor for your accessibility convenience and simplicity of usage for Gaming Desktop Motherboard
• 4 USB 2.0 ports offer the impressive data transfer speed of up to 60 Mb/sec

TECHNICAL SPECS

• Chipset Manufacturer: AMD
• Chipset Model: B650
• Total Processor Supported: 1
• Processor Socket: Socket AM5
• Processor Supported
  • Ryzen 7
  • Ryzen 5
• Multi GPU Supported: CrossFire
• Number of Memory Slots: 4
• Memory Form Factor
  • DIMM
  • UDIMM
• Maximum Memory Supported: 192 GB
• Memory Technology: DDR5 SDRAM
• Memory Speed Supported: 7200 MHz
• Controller Type: Serial ATA/600
• RAID Supported: Yes
• RAID Levels
  • 0
  • 1
  • 10
• Onboard Video: CPU Dependent Video
• Graphics Controller Model: RDNA graphics
• Audio Channels: 7.1
• Bluetooth: Yes
• Bluetooth Standard: Bluetooth 5.2
• Gigabit Ethernet: Yes
• 2.5Gigabit Ethernet: Yes
• Wireless LAN: Yes
• Wireless LAN Standard: IEEE 802.11 a/b/g/n/ac/ax
• PCI Express Standard
  • PCI Express 4.0
  • PCI Express 3.0
• Total Number of PCI Express Slots: 2
• Number of PCI Express x16 Slots: 2
• Total Number of USB Ports: 8
• Number of USB 2.0 Ports: 4
• Number of USB 3.2 Gen 1 Type-A Ports: 2
• Number of USB 3.2 Gen 2 Type-A Ports: 1
• Number of USB 3.2 Gen 2 Type-C Ports: 1
• VGA: Yes
• HDMI: Yes
• HDMI Version: 2.1
• DisplayPort: Yes
• Number of Network (RJ-45) Ports: 1
• Thunderbolt: Yes
• Number of Thunderbolt 4 Ports: 1
• Number of M.2 Interfaces: 3
• Total Number of Onboard USB Ports: 9
• Number of Onboard USB 2.0 Ports: 4
• Form Factor: Micro ATX
• Width: 9.6"
• Depth: 9.6"

OTHER INFORMATION

• Energy Efficiency Compliance
  • Energy-related Products Directive Ready (ErP Ready)
  • Energy-using Products Directive Ready (EuP Ready)
• Environmental Compliance
  • Waste Electrical and Electronic Equipment Directive (WEEE)
  • Taiwan Restriction of Hazardous Substances (Taiwan RoHS)
  • China Restriction of Hazardous Substances (China RoHS)
  • Restriction of Hazardous Substances (RoHS)
