Dynatron K5 FAN CPU Cooler LGA1156 1155 92x25mm Mini ITX Aluminum Heatsink Fin

Detail Specifications

• CPU Support: Intel
• CPU Socket: LGA 115X/1200
• Screw Type: M3
• Installation Torque: 5-7 in-lb
• Solution: 1.5U Server, mini-ITX
• Dimensions: 92.0 x 92.0 x 41.0 mm
• Weight: 200g ± 5g
• Material: Aluminum Extruded Radial Fin
• Fan Dimension: 92 x 92 x 25 mm
• Speed
  • At Duty Cycle 0~20%: 1000 RPM
  • At Duty Cycle 50%: 1400 RPM
  • At Duty Cycle 100%: 2500 RPM
• Rated Voltage: 12V
• Bearing: 2 Ball Bearing
• Power
  • At Duty Cycle 0~20%: 0.72 W
  • At Duty Cycle 50%: 1.08 W
  • At Duty Cycle 100%: 3.6 W
• Air Flow
  • At Duty Cycle 0~20%: 14.98 CFM
  • At Duty Cycle 50%: 29.90 CFM
  • At Duty Cycle 100%: 46.96 CFM
• Noise Level
  • At Duty Cycle 0~20%: 14.70 dBA
  • At Duty Cycle 50%: 18.50 dBA
  • At Duty Cycle 100%: 29.85 dBA
• Air Pressure
  • At Duty Cycle 0~20%: 0.29 mm-H2O
  • At Duty Cycle 50%: 1.07 mm-H2O
  • At Duty Cycle 100%: 2.98 mm-H2O
• Lead Wire Pin Out
  • Pin1- (-)
  • Pin2- (+)
  • Pin3- (Techometer/Signal output)
  • Pin4- (PWM)
• Life- Continuous operating under normal temperature (40°C/104 °F):0,000 Hours
• Item Dimension (L"xW"xH"): 3.66 x 3.66 x 2.64
• Weight: 1 lb
