Elastix NLX4000 VoIP IP UCS Rack PBX 300 Ext VoiceMail IVR Conf 1 T1/E1 PRI w EC

Model: NLX4000-DE13  PBX

What's Included in this Package

Base Unit NLX4000

T1/E1 PRI: 1 Ports

Echo Module: Yes

Power: 110-220V   USA NA Plug

General Information

• Manufacturer: Elastix
• Model: NLX4000-DE13
• The NLX4000 is a unified communications server designed for medium and high performance environments in medium and large-sized businesses.
• The devices comes with pre-installed Elastix software and telephony integration configurable according to the customer’s needs. Telephony integration is achieved through an efficient system of quickly interchangeable trays without compromising the server’s internal components.
• The NLX4000 is ideal for scenarios requiring high availability thanks to its ability of integrating two drives, hardware RAID, and redundant power supply.
• Elastix is an Open Source solution. You will not have to pay for licensing costs associated with the operation of your NLX4000.

Tech Specs:

• Telephony
• Analog Ports (FXO/FXS): Configurable up to 48*
• Digital Ports: Up to 4 E1/T1/J1*
• Extensions (SIP/IAX): Up to 300
• Concurrent Calls: 120
• PCI Expansion slots: 2 PCIe – easy swap
• Operating System: Elastix 32 bits – supports 64 bits

Hardware

• CPU: 1.86 GHz Dual Core
• RAM: 4 GB DDR3
• Hard Drive: 500 GB HDD – 2.5?
• 2nd Hard Drive: 500 GB HDD – 2.5? (optional)**
• RAID: Software by default**
• Network Interfaces : 2 x Gigabit Ethernet
• LCD Display: Front panel
• USB Ports: 2

Operating Characteristics

• Nominal Power: 150 W, PSU efficient
• Operating Voltage: 110-220 V / Autoswitching

Physical Characteristics

Case Height    1.5U – Mountable rack of 19?

*The device is by default distributed without telephony integration. Refer to your nearest distributor for factory configuration options.

**The options of a second hard drive, hardware RAID, and redundant power supply are distributed on demand. RAID option is available when the device is distributed with two hard disk drives.

Key Features:

•     Availability of redundancy in hard drive disks
•     Effective maintenance-oriented design
•     Frontal and non-invasive access to hard drives
•     Redundant power supply, on demand
•     Software RAID by default
•     Hardware RAID on demand
•     Potential for high availability in 1.5U
•     Ethernet Gigabit network interface
•     Telephony integration versatility
•     Non-invasive installation of telephony integration
•     Hardware Detection interface
•     Support for Analog interfaces like FXS/FXO (PSTN/POTS)
•     Support for Digital interfaces like E1/T1/J1 through PRI/BRI/R2 protocols
•     Integrated Echo Cancellation
•     Distributed dialplan with Dundi
•     Over a 100 basic and advanced PBX configurations

And many other features available in Elastix…

Extend functionality for your NLX4000 with over 30 additional solutions through the Elastix Addons program
