Intel BX80768245KF Core Ultra 5 CPU Processor 245KF 14 Cores 24M 5.2G LGA18W BOX

The Intel BX Series Processors are all in Original, Brand New Intel Retail Packaging. This item is NOT returnable. Warranty is handled directly by Intel.

Intel® Core™ Ultra 5 Processor 245KF (24M Cache- up to 5.20 GHz)

Essentials

• Product Collection: Intel® Core™ Ultra Processors (Series 2)
• Code Name: Products formerly Arrow Lake
• Vertical Segment: Desktop
• Processor Number: 245KF
• Overall Peak TOPS (Int8): 22

CPU Specifications

• Total Cores: 14
• # of Performance-cores: 6
• # of Efficient-cores: 8
• Total Threads: 14
• Max Turbo Frequency: 5.2 GHz
• Performance-core Max Turbo Frequency: 5.2 GHz
• Efficient-core Max Turbo Frequency: 4.6 GHz
• Performance-core Base Frequency: 4.2 GHz
• Efficient-core Base Frequency: 3.6 GHz
• Cache: 24 MB Intel® Smart Cache
• Total L2 Cache: 26 MB
• Processor Base Power: 125 W
• Maximum Turbo Power: 159 W
• Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
• AI Software Frameworks Supported by CPU: OpenVINO™ |  WindowsML |  DirectML |  ONNX RT |  WebNN
• CPU Lithography: TSMC N3B

Supplemental Information

• Marketing Status: Launched
• Launch Date: Q4'24
• Embedded Options Available: No
• Use Conditions: PC/Client/Tablet

Memory Specifications

• Max Memory Size (dependent on memory type): 192 GB
• Memory Types: Up to DDR5 6400 MT/s
• Maximum Memory Speed: 6400 MHz
• Max # of Memory Channels: 2

NPU Specifications

• NPU Name‡: Intel® AI Boost
• NPU Peak TOPS (Int8): 13
• Sparsity Support: Yes
• Windows Studio Effects Support: Yes
• AI Software Frameworks Supported by NPU: OpenVINO™ |  WindowsML |  DirectML |  ONNX RT |  WebNN

Expansion Options

• Direct Media Interface (DMI) Revision: 4
• Max # of DMI Lanes: 8
• Intel® Thunderbolt™ 4: Yes
• Scalability: 1S Only
• PCI Express Revision: 5.0 and 4.0
• PCI Express Configurations ‡: Up to 1x16+2x4 |  2x8+2x4 | 1x8+4x4
• Max # of PCI Express Lanes: 24

Package Specifications

• Sockets Supported: FCLGA1851
• Thermal Solution Specification: PCG 2020A
• Max Operating Temperature: 105 °C

Advanced Technologies

• Intel® Volume Management Device (VMD): Yes
• Intel® Gaussian & Neural Accelerator: 3.5
• Intel® Thread Director: Yes
• Intel® Speed Shift Technology: Yes
• Intel® Turbo Boost Technology ‡: 2.0
• Intel® 64 ‡: Yes
• Instruction Set: 64-bit
• Instruction Set Extensions: Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2
• Idle States: Yes
• Enhanced Intel SpeedStep® Technology: Yes
• Thermal Monitoring Technologies: Yes

Security & Reliability

• Intel® Standard Manageability (ISM) ‡: Yes
• Intel® Control-Flow Enforcement Technology: Yes
• Intel® AES New Instructions: Yes
• Secure Key: Yes
• Intel® Trusted Execution Technology ‡: Yes
• Execute Disable Bit ‡: Yes
• Intel® OS Guard: Yes
• Intel® Boot Guard: Yes
• Mode-based Execute Control (MBEC): Yes
• Intel® Virtualization Technology (VT-x) ‡: Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes
• Intel® VT-x with Extended Page Tables (EPT) ‡: Yes
