Netgear GS752TXUP-300NAS 48 Port 4 Dedicated 10G SFP+ Business Ethernet Switch

GENERAL INFORMATION

• Manufacturer: Netgear, Inc
• Manufacturer Part Number: GS752TXUP-300NAS
• Brand Name: Netgear
• Product Line: Business
• Product Model: GS752TXUPv3
• Product Name: Business GS752TXUPv3 Ethernet Switch
• Product Type: Ethernet Switch

FEATURES:

• DHCP Snooping
• Remote/Cloud Management
• Access Control List
• Energy Efficient
• Zero-Touch Provisioning (ZTP)
• VLAN Segmentation
• Dynamic ARP Inspection
• Remote Monitoring (RMON)
• DHCP Relay

INTERFACES/PORTS

• Total Number of Network Ports: 48
• Uplink Port: Yes
• Network (RJ-45): Yes
• Port/Expansion Slot Details:
  • 32 x 10/100/ 1000BASE-T Gigabit Ethernet PoE+ RJ-45 Network Port
  • 16 x 10/100/ 1000BASE-T Gigabit Ethernet PoE++ RJ-45 Network Port
  • 4 x 1000/10GBASE-X Gigabit Ethernet SFP+ Expansion Slot

MEDIA & PERFORMANCE

• Media Type Supported:
  • Optical Fiber
  • Twisted Pair
• Ethernet Technology:
  • Gigabit Ethernet
  • 10 Gigabit Ethernet
• Network Technology:
  • 10GBase-X
  • 10/100/1000Base-T
  • 1000Base-X
• Maximum Data Transfer Rate: 1.25 GB/s

I/O EXPANSIONS

• Total Number of Expansion Slots: 4
• Expansion Slot Type: SFP+
• Number of SFP+ Slots: 4

NETWORK & COMMUNICATION

• Layer Supported: 3
• Networking Standards:
  • IEEE 802.1x
  • IEEE 802.1Q
  • IEEE 802.3ad
  • IEEE 802.3x
  • IEEE 802.1p
  • IEEE 802.3az
  • IEEE 802.11ac
  • IEEE 802.1D
  • IEEE 802.1w
  • IEEE 802.1s
  • IEEE 802.1ab
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3z
  • IEEE 802.3at
  • IEEE 802.3bt

MANAGEMENT

• Manageable: Yes

RELIABILITY

• MTBF: 191643 Hour

POWER DESCRIPTION

• PoE (RJ-45) Port: Yes
• PoE Budget: 640 W
• Power Source:
  • Power Supply
  • PoE+
  • PoE++
• Number of Power Supplies Installed: 1
• Power Consumption: 763 W

PHYSICAL CHARACTERISTICS

• Form Factor:
  • Rack-mountable
  • Desktop
  • Table Top
• Height: 1.7"
• Width: 17.3"
• Depth: 12.4"
• Weight (Approximate): 10.56 lb

PACKAGE CONTENTS

• Business GS752TXUPv3 Ethernet Switch
• AC Power Cord With C13 Connector
• Brackets and Screws For Rack Mounting
• Rubber Footpads For Tabletop Installation
• Rubber Protection Caps
• Installation Guide

CERITICATIONS

• Electromagnetic Emissions and Immunity
  • CE
  • FCC Class A
  • RCM
  • ICES Class A
  • VCCI
  • KC
  • BSMI
  • UKCA
• Safety
  • CB
  • CE
  • CSA
  • RCM
  • KC
  • BSMI
