Samsung MZTL615THBLF-00AW7 PM9D3a 15.36TB E1.S(9.5mmT) PCI Express Gen.5 x4 SSD

MPN: MZTL615THBLF-00AW7

Main Features

• Capacity: 15.36TB
• Features
• PCI Express Gen.5
• PCI Express CEM Specification Rev. 5.0
• PCI Express Base Specification Rev. 5.0
• NVM Express Specification Rev. 2.0
• Single port x4 lanes
• Enhanced Power-Loss Data Protection
• End-to-End Data Protection
• Support SSD Enhanced S.M.A.R.T. Feature Set
• Hardware based AES-XTS 256-bit Encryption Engine
• Static and Dynamic Wear Leveling
• RoHS / Halogen-Free Compliant
• TCG Opal 2.02 Compliant
• OCP 2.5 compliant
• Drive Configuration
• Form Factor: E1.S(9.5mmT)
• Interface: PCI Express Gen.5 x4
• Bytes per Sector: 512(default), 520, 4096, 4160 Bytes
• Performance Specifications)
• Data Transfer Rate (128KB data size):
• Sequential Read: Up to 12,000 MB/s
• Sequential Write: Up to 6,800 MB/s
• Data I/O Speed (4KB data size, Sustained):
• Random Read: Up to 2,000K IOPS
• Random Write: Up to 350K IOPS
• Latency (Sustained workload):
• Random Read/ Write (typical): Up to 65/9 us
• Sequential Read/ Write (typical): Up to 9/9 us
• Drive Ready Time (typical): 5s
• Reliability Specifications
• Uncorrectable Bit Error Rate: 1 sector per 10^17 bits read
• MTBF: 2,500,000 hours
• Endurance (JEDEC Workload): 1 DWPD
• TBW (JEDEC Workload): 28,032 TB
• Data Retention: 3 months
• Environmental Specifications
• Temperature:
• Operating: 0 ~ 70 °C
• Non-operating: -40 ~ 85 °C
• Humidity (non-condensing): 5 ~ 95%
• Linear Shock (0.5ms duration with 1/2 sine wave): Non-operating: 1,500 G
• Vibration (20 ~ 2,000 Hz, Sinusoidal): Non-operating: 20G
• Power Requirements: Supply Voltage / Tolerance: 12V+/-10%
• Power Consumption
• Active: Read: 16.0 W; Write: 17.5 W
• Idle (typ.): Up to 4.5 W
• Physical Specifications
• Width: 33.75 +/- 0.25mm
• Length: 118.75 +/- 025mm
• Height: 9.50 +/- 0.35mmT
• Weight: Avg. 67.0g
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.
