Samsung MZVLC512HFJD-00B07 512GB PCI Express Gen.5 x4 M.2 Solid State Drive

MPN: MZVLC512HFJD-00B07

Main Features

• PCIe Gen.5 32Gb/s Interface, up to 4 Lanes
• PCI Express Base Specification Rev. 5.0
• PCI Express M.2 Specification Rev. 5.0
• NVM ExpressTM specification Rev. 2.0c
• Power Saving Modes:
• Supporting APST
• Supporting L1.2 Mode
• Support Admin & NVM Command Set
• RoHS / Halogen Free Compliant
• Hardware based AES-XTS 256-bit Encryption Engine for SED
• TCG OPAL (v2.0) Compliant for SED
• Drive Configuration
• Capacity: 512GB
• Form Factor: M.2
• Interface: PCI Express Gen.5 x4
• Bytes per Sector: 512 Bytes
• Performance Specifications
• Data Transfer Rate (128KB)
• Sequential Read: Up to 12,200 MB/s
• Sequential Write: Up to 6,300 MB/s
• Random Read: Up to 800 KIOPS
• Random Write: Up to 1,360 KIOPS
• Reliability Specifications
• Uncorrectable Bit Error Rate: < 1 sector per 10^15 bits read
• MTBF: 1.5 Million Hours
• Environmental Specifications
• Temperature:
• Operating: 0°C to 70°C
• Non-operating: -40°C to 85°C
• Humidity (non-condensing): Non-operating: 5 ~ 95%
• Linear Shock: Non-operating (0.5ms duration with 1/2 sine wave): 1500 Gpeak
• Vibration: Non-operating (20 ~ 2,000 Hz, Sinusoidal): 20 G
• Power Specifications
• Supply Voltage / Tolerance: 3.3V +/- 5%
• Active (Typ, RMS):
• Read (3.3V): 8.8 W
• Write (3.3V): 8.6 W
• Idle (Typ.): 10 mW
• Sleep (Typ): 5 mW
• Physical Dimension
• Width: 22.00 +/- 0.15 mm
• Length: 80.00 +/- 0.15 mm
• Height Max.: 2.38 mm
• Weight: Under 9.0g
