Samsung MZWMO30THCLF-00AW7 BM1743 30.72TB 2.5-inch U.2 PCI Express Gen.4 x4 SSD

MPN: MZWMO30THCLF-00AW7

Main Features

• Features
• -PCI Express Gen.4
• -PCI Express Base Specification Rev. 4.0
• -NVM ExpressTM Specification Rev. 1.4b
• -NVM ExpressTM Management Interface Specification Rev. 1.1b
• -Single port X4 lanes/ Dual port x2 lanes
• -Enhanced Power-Loss Data Protection
• -End-to-End Data Protection
• -Support SSD Enhanced S.M.A.R.T. Feature Set
• -Hardware based AES-XTS 256-bit Encryption Engine
• -Static and Dynamic Wear Leveling
• -RoHS / Halogen-Free Compliant
• Capacity: 30.72TB
• Drive Configuration
• -From Factor: 2.5-inch, U.2
• -Interface: PCI Express Gen.4 x4
• -Bytes per Sector: 512(default), 520, 4096, 4104, 4112, 4160Bytes
• Performance Specifications
• -Data Transfer Rate (128KB data size): Sequential Read: Up to 7,300 MB/s; Sequential Write: Up to 2,000 MB/s
• -Data I/O Speed (4KB data size, Sustained): Random Read: Up to 1,700KIOPS; Random Write: Up to 110 KIOPS
• -Latency (Sustained workload): Read / Write (typical): Up to 150 us/ 20 us; Drive Ready Time (typical) Up to 1 Sec
• -Quality of service: Read / Write (99%): Up to 200 us/ 25 us
• Reliability Specifications
• -Uncorrectable Bit Error Rate: 1 sector per 10^17 bits read
• -MTBF: 2,500,000 hours
• -Endurance: 0.26 DWPD
• -TBW (@JEDEC Workload): 14.576 PB
• -Data Retention: 3 month
• Environmental Specifications
• -Temperature: Operating (Tcomp): 0 ~ 70 °C; Non-operating -40 ~ 85 °C
• -Humidity (Non-condensing): 5 ~ 95%
• -Shock: Non-operating/ Operating: 1,500 G / 0.5msec
• -Vibration (20~2,000Hz, Sweep sine): Non-operating/ Operating: 20G
• -Power Requirements: Supply Voltage / Tolerance: 12V +/- 10%
• Power Consumptions
• -Read Power: 23.8 W
• -Write Power: 24.7 W
• -Idle (typ.): 5 W
• Physical Dimension
• -Width: 69.85 +/- 0.25mm
• -Length: 100.20 +/- 0.25mm
• -Height: 15.00 +0.00/-0.50mm
• -Weight: Up to 165.8 g
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.
