Samsung QB24C 24" LFD UHD LED Tizen 7.0 Display

KEY FEATURES

• Full HD (1920 x 1080) Native Resolution
• ADS LED Panel
• EMC Class B & IP5X Certified
• RS-232C & LAN Controllable
• 1 x HDMI Input
• 1000:1 Static Contrast Ratio
• 250 nits Brightness | 25% Haze level
• Digital Signage Support with Tizen SoC
• 16/7 Duty Cycle | Portrait & Landscape
• Built-In Wi-Fi

KEY SPECS

• Display Size: 23.8"
• Native Resolution: 1920 x 1080
• Maximum Brightness: 250 nits / cd/m2
• Touchscreen: No
• Inputs: 1x HDMI 1.4
• Outputs: 1x 1/8" / 3.5 mm (Analog Audio)
• Wireless: Wi-Fi / Bluetooth / IR
• USB I/O: 1x USB-A (Unspecified Version) (Photo/Audio/Charging/Video)
• Ethernet I/O: 1x RJ45 10/100 Mb/s Ethernet
• Other I/O:
  • 1x 1/8" / 3.5 mm Serial (RS-232C) Control Input
  • 1x 1/8" / 3.5 mm IR Input
• Built-In Speakers: No

DISPLAY

• Display Size: 23.8"
• Panel Type: IPS-Type LCD
• Aspect Ratio: 16:9
• Display Orientation: Landscape, Portrait
• Native Resolution: 1920 x 1080
• Maximum Brightness: 250 nits / cd/m2
• HDR Support: No
• Contrast Ratio: 1000:1
• Response Time: 14 ms
• Refresh Rate: 60 Hz
• Color Gamut: 72% Rec. 2020
• Viewing Angle (H x V): 178 x 178°
• Horizontal Frequency: 56 to 84.5 kHz
• Vertical Frequency: 48 to 75 Hz
• Finish: Anti-Glare / Matte

SURFACE

• Touchscreen: No
• Haze Level: 25%

VIDEO

• TV Tuner: No
• CONNECTIVITY
• Inputs: 1x HDMI 1.4
• Outputs: 1x 1/8" / 3.5 mm (Analog Audio)
• HDCP Support: Yes, Version 2.2
• Wireless: Wi-Fi / Bluetooth / IR
• USB I/O: 1x USB-A (Unspecified Version) (Photo/Audio/Charging/Video)
• Ethernet I/O: 1x RJ45 10/100 Mb/s Ethernet
• Other I/O:
  • 1x 1/8" / 3.5 mm Serial (RS-232C) Control Input
  • 1x 1/8" / 3.5 mm IR Input
• Multi-Input Support (PIP/PBP): No

SPEAKER

• Built-In Speakers: No
• Audio Processing: Dolby Digital, Dolby Digital Plus

HARDWARE

• Smart TV: Yes, Tizen 7.0
• Storage: 8 GB
• OS Compatibility:
  • Computer: Windows / macOS / Linux
  • Mobile: Android/iOS
• Built-In Mic: No

SUPPORTED FILE FORMATS

• SUPPORTED VIDEO FILE TYPES: 3GP, ASF, AVI, FLV, H.263, H.264/AVC, H.265/HEVC, M2TS, MJPEG, MKV, MOV, MP4, MPEG, MPEG2, MPEG4, MPG, MTS, RMVB, SVI, TP, TRP, TS, VOB, VP8, VP9, VRO, WEBM, WMV
• Supported Audio File Types: AAC, AC-4, ADPCM-WAV, HE-AAC, LPCM, MP3, WMA

ELECTRICAL

• Power Consumption: Operational: 38.5 W
• Input Power: 100 to 240 VAC, 50 / 60 Hz
• Power Adapter Type: Internal

GENERAL

• Operating Conditions: 32 to 104°F / 0 to 40°C at 10 to 80% Humidity
• Certifications: CB, FCC Part 15, Subpart B, IEC, Kcc/EK, PSB, RoHS, cUL60950
• VESA Mounting-Hole Pattern: 100 x 100 mm
• Environmental Resistance: Dust-Resistant (IP5X)
• Impact Resistance: No
• Bezel Thickness:
  • 9.4 mm (Right/Left)
  • 17.9 mm (Bottom/Top)
• Duty Cycle: 16 Hours / 7 Days
• Dimensions: 21.6 x 13.2 x 1.3" / 547.9 x 334.4 x 31.8 mm
• Weight: 6.6 lb / 3 kg

PACKAGING INFO

• Package Weight: 8.7 lb
• Box Dimensions (LxWxH): 24.5 x 16.5 x 4.7"
