Synology DS223 NAS 2bay DiskStation (Diskless) Retail

Write a review

$331.38

Brand : Synology

Collection : NAS Appliance

Product Type : NAS

SKU : AS24a 271660 - DS223

Availability : 2 In Stock Sold Out 2

HURRY ! ONLY 2 LEFT IN STOCK.

Translation missing: en.products.product.product_variants

Quantity

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Security

FREE SHIPPING

Anywhere in the USA

BIG SAVING ON

WEEKENDS

24H SUPPORT

Description
Shipping

Vendor: Synology
SKU: 271660
MPN: DS223

Marketing Information
DiskStation DS223
Data management platform for home and small office

Get your data under control
Consolidate files from various sources into your own private cloud.
The DS223 keeps the process simple and offers everything you need to keep your data safe and organized.
• Secure private cloud
Enable anywhere, anytime access to up to 36 TB of data.
(Raw capacity. Usable storage capacity may vary depending on drives used and RAID configuration.)
• Simple backup hub
Create spare copies of your documents and media for easy recovery.
• Efficient operation
Keep energy consumption low with just 17.3 W during operation.

Private cloud made easy
Import data from PCs, Macs, and other external storage devices at a 14% faster rate and keep all your devices in sync for smoother file management.

Access from any device
Get to your files from PC, Mac, Linux, Chromebook, Android, iOS, or any device equipped with a browser. Keep your data private or easily share it using secure links.

Save storage space
Enable on-demand mode to download files onto your Windows PC or Mac only when you access them. Pin the most important ones or the ones you access more frequently for convenient offline accessibility.

Integrate with the cloud
Sync files between your private cloud and public cloud services, including Google Drive, Dropbox, and Microsoft OneDrive. Retain local copies of your cloud data for centralized management and data ownership.

Sync across locations
Say goodbye to long waits while downloading or uploading files. Continuously synchronize content between two Synology devices to enable fast local access at any location, no matter the amount of data.

Detail Specifications
Hardware Specs
CPU
CPU Model
Realtek RTD1619B
CPU Quantity
1
CPU Architecture
64-bit
CPU Frequency
4-core 1.7 GHz
Hardware Encryption Engine
Yes
Memory
System Memory
2 GB DDR4 non-ECC
Notes
Synology reserves the right to replace memory modules with the same or higher frequency based on suppliers product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays
2
Compatible Drive Type
3.5" SATA HDD
2.5" SATA SSD
Hot Swappable Drive
Yes
Notes
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port
1
USB 3.2 Gen 1 Port
3
USB / SD Copy
Yes
Notes
This devices 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
File System
Internal Drives
Btrfs
EXT4
External Drives
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT
Others
System Fan
92 mm x 92 mm x 1 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
Yes
Power Recovery
Yes
Noise Level
14.6 dB(A)
Scheduled Power On / Off
Yes
Wake on LAN / WAN
Yes
Power Supply Unit / Adapter
60 W
AC Input Power Voltage
100V to 240V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption
17.343 W (Access)
4.08 W (HDD Hibernation)
British Thermal Unit
59.19 BTU/hr (Access)
13.92 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A), Temperature: 24.25-25.75oC , Humidity: 58.2-61.8%.
Temperature
Operating Temperature
0oC to 40oC (32oF to 104oF)
Storage Temperature
-20oC to 60oC (-5oF to 140oF)
Relative Humidity
5% to 95% RH
Certification
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
Environment
RoHS Compliant
Packaging Content
Main Unit X 1
Accessory Pack X 1
AC Power Adapter X 1
AC Power Cord X 1
RJ-45 LAN Cable X 1
Quick Installation Guide X 1
Optional Accessories
3.5" SATA HDD: HAT5300
2.5" SATA SSD: SAT5210
VisualStation: VS360HD
Surveillance Device License Pack
Software Specs
DSM Specifications
Storage Management
Maximum Single Volume SizeNote
108 TB
Maximum Internal Volume Number
64
SSD TRIM
Yes
Supported RAID Type
Synology Hybrid RAID
Basic
JBOD
RAID 0
RAID 1
RAID Migration
Basic to RAID 1
Volume Expansion with Larger HDDs
Synology Hybrid RAID
RAID 1
Volume Expansion by Adding a HDD
Synology Hybrid RAID
Notes
1.Usable capacity for each volume will be lower than the maximum volume size and is dependent on the filesystem and the amount of system metadata stored.
2.Actual maximum storage pool and volume sizes depend on drive sizes used, the number of drive bays available, and the RAID configuration.
File Services
File Protocol
SMB/AFP/NFS/FTP/WebDAV
Maximum Concurrent SMB/AFP/FTP Connections
200
Windows Access Control List (ACL) Integration
Yes
NFS Kerberos Authentication
Yes
Notes
The testing standard was based on the maximum number of concurrent connections supported by this model. During the testing, 25% of the connections were used to transfer files concurrently. The transfer process guaranteed that the connections were not interrupted, the minimum transfer speed was not guaranteed.
Account and Shared Folder
Maximum Local User Accounts
1,024
Maximum Local Groups
256
Maximum Shared Folder
256
Maximum Shared Folder Sync Tasks
4
Hybrid Share
Hybrid Share Folder Number
5
Log Center
Syslog Events per Second
400
General Specifications
Networking Protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
Google Chrome
Firefox
Microsoft Edge
Safari
Supported Language
English, Deutsch, Franais, Italiano, Espaol, Dansk, Norsk, Svenska, Nederlands, , Polski, Magyar, Portugus do Brasil, Portugus Europeu, Trke, esk, , , , ,
Notes
For an updated list of supported browser versions, check the DSM Technical Specifications.
Synology Chat
Yes
Download Station
Maximum Concurrent Download Tasks
80
SAN Manager
Maximum iSCSI Target Number
10
Maximum LUN
10
LUN Clone/Snapshot, Windows ODX
Yes
Media Server
DLNA Compliance
Yes
Synology Photos
Facial Recognition
Yes
Snapshot Replication
Maximum Snapshots per Shared Folder
256
Maximum of System Snapshots
4,096
Surveillance Station
Maximum IP cam (Licenses required)
20 (including 2 Free License) (see all supported IP cameras)
Total FPS (H.264)
600 FPS at 720p (1280x720)
460 FPS at 1080p (1920x1080)
300 FPS at 3M (2048x1536)
150 FPS at 5M (2591x1944)
110 FPS at 4K (3840x2160)
Total FPS (H.265)
600 FPS at 720p (1280x720)
500 FPS at 1080p (1920x1080)
400 FPS at 3M (2048x1536)
350 FPS at 5M (2591x1944)
200 FPS at 4K (3840x2160)
Notes
1.Maximum IP cameras and FPS figures are tested with the device fully populated with drives and under a continuous recording setup.
2.Actual system capabilities may differ depending on system configuration, drive performance, number of features enabled, and if additional workloads are present.
Synology Drive
Recommended Number of Concurrent Sync Clients
200 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Recommended Number of Hosted Files
500,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Notes
1.Exceeding the recommended numbers above will not block application operations, but may result in longer response time.
2.Btrfs file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office
Maximum Users
200
Notes
1.Multiple files were opened for testing and each file was edited by 30 users simultaneously.
2.Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station
Yes
VPN Serve
Maximum Connections
20

Warranty Information
2 Years - Direct from the Manufacturer
