Vendor: Openvox

OpenVox UC300-A14EM1 SOHO Desktop 60 Users PBX with 1 FXS 4 FXO

SKU: UC300-A14EM1
Regular price $527.12 Sale price $527.12 Regular price $599.00
Save $71.88 $71.88 ($71.88)
Shipping calculated at checkout.

Orders received by 10 am are shipped on the same business day. Mondays through Saturday.

In stock: 1

THe UC300 is a cost effective SoHo PBX. This PBX series comes in 2 model offering:

  • UC300-A11EM1. 1 FXO 1 FXS
  • UC300-A14EM1. 1 FXO 4 FXS


  • 1 Year Limited Manufacturer Warranty



The UC300 Series support analog FXO/FXS ports with up to 300 simultaneous calls in one single device. They are developed with a wide selection of codecs and signaling protocols, including ADPCM,G.711A,G.711U,G.722,G.723.1,G.726,G.728,G.729,ILBC. Taking full advantages of open source platform, the UC300 Series support industry standard SIP trunks, IAX2 trunks, analog PSTN trunks, and analog station trunks.

No licenses to pay.

  • Up to 800 extension register
  • 100 concurrent calls with G.729 codec
  • 300 concurrent calls with G.711 codec
  • Recording: 86,000 mins (compressed); 9,500 mins (.wav)
  • Voicemail: 86,000 mins (compressed); 9,500 mins (.wav)
  • Network Interface: 1×10/100M LAN port
  • USB Port: 1×USB 2.0 for external storage or disaster recovery system
  • External Storage: 1×SD slot, support up to 128G
  • Telephony Interfaces: FXS/FXO interface, Optional Storage: 16GB Onboard Flash
  • RAM: DDR3 1GB
  • 1 MIC Interface: Audio Input
  • 1 SPK Interface: Audio Output
  • Power Consumption: 12V/0.8A, 9.6W Maximum
  • Failover Function (not support with 2 FXO model) Operational Temperature: 0°C to 50 °C
  • Storage Temperature: -20 °C to 65 °C Size: 130*130*40mm
  • Weight: 530g


  • DHCP Server
  • DHCP Client List
  • Assign IP Address to Host


  • Firewall
  • Audit
  • Weak keys
  • UC300-A14EM1
  • 12V Power Adapter NA
  • Ethernet Cord
